Preinstallation Checklist for Natura Countertop Systems

Countertop Pre-Installation Checklist

Please complete all required fields before installation is scheduled.

Installation Information

Establishment Name *

Address *

City *

State *

Zip Code *

Contact Person *

Phone Number *

Email *

System Serial # *

Signature (type full name) *

Date of Survey *

1. Water Supply *

1.1 Water supply shut-off valve that can adapt to a 3/8" compression fitting within 5' (1.5 m) of the machine location. 1.2 Shut-off valve that will only be used for the Natura unit. Espresso machines, coffee makers, ice machines, etc. cannot be attached to the same shut-off valve. This includes T-ing off of the Filter Box. These lines must be solely used for the Natura Water system. 1.3 Maximum inlet water temperature of 75°F (24°C). A high inlet water temperature will affect chilled water capacity. 1.4 Minimum inlet water flow rate of 2.2 gallons/min. 1.5 Water pressure range: 45 PSI – 120 PSI.

2. Dedicated CO₂ + Electrical Supply *

2.1 Dedicated CO₂ canister on-site within 5' of machine location (standard tanks are 5–50 lbs UN1013 Food Grade gas). 2.2 Electrical supply available within 5' of machine location: 115V for B5/D5 1.35; 230V for B5i/D5i.

3. For Bulk CO₂ Connection Only (to be hooked up by CO₂ supplier)

3.1 Dedicated CO₂ connection line from the bulk CO₂ canister requires the bulk tank to have a dedicated CO₂ regulator. 3.2 Dedicated CO₂ connection line from bulk CO₂ canister requires a different regulator (NOT SUPPLIED BY NATURA) within 5' of the machine location. 3.3 Dedicated CO₂ connection line from bulk CO₂ canister requires a minimum pressure rating of 100 PSI. 3.4 Dedicated CO₂ connection line from bulk CO₂ canister requires the pressure regulator set at 60 PSI. Setting above 60 PSI will damage the unit and void the warranty. This section is completed by the CO₂ supplier and is not required to submit the form.

5. Installation Description & Photo *

5.1 Brief description of where the machine will be installed *

Image (optional)

Slide title

Slide title

Countertop Pre-Installation Checklist

Prior to Installation Customer is responsible for...
